ABB 3BHE024415R0101 IGCT Module

ABB 3BHE024415R0101 IGCT Module

Specifications

The application scope of 3BHE024415R0101 IGCT covers high-power scenarios such as transmission networks,

wind power, rail transit, and metallurgy. Due to its simpler structure and smaller size, the frequency converter using

IGCT can demonstrate better performance and cost advantages in terms of design difficulty, heat dissipation, and

robustness.　　The working principle of 3BHE024415R0101 IGCT is to apply a forward voltage to the internal PN

junction area, injecting holes and electrons from the PN junction area into the N-type and P-type induction layers

to form an induced current. At the same time, a certain voltage signal is applied to the gate electrode of IGCT to

control the conduction and cutoff of the entire device by controlling the recombination and displacement of holes

and electrons in the PN junction region. Specifically, There are three electrodes in IGCT devices: cathode, anode,

and gate. If a negative voltage is applied to the gate or the power supply to the gate is disconnected, The electrons

and holes in the PN junction region will quickly recombine and move, thereby cutting off the conduction of the

entire device.

Product Applications

Oil & Gas: Widely used in the control of driving systems in oil refineries and oil pipelines.
Mining & Metals: Used in rolling mills of steel plants, mining transportation equipment, and high-pressure

injection pump systems.
Power & Energy: Applied in power plants and power transmission systems, suitable for in substations and grid

monitoring, etc., for high-power conversion processes.
Chemical Industry: As a core component in large fans and pumps of this industry's equipment.
