WOODWARD 8440-2152 Circuit Breaker Relay Module

WOODWARD 8440-2152 Circuit Breaker Relay Module

✦Product Parameters

Rated Power Supply: 12/24 Vdc (operating range: 8 to 40 Vdc)
Power Consumption: Max. ~5 W (LS-511), Max. ~6 W (LS-521)
Operating Temperature Range: -20 to 70 °C (-4 to 158 °F)
Storage Temperature Range: -30 to 80 °C (-22 to 176 °F)
Ambient Humidity: 95% non-condensing
Voltage Inputs:
69/120 Vac Rated: Max. 86/150 Vac, Phase-Ground 150 Vac, Surge 2.5 kV
277/480 Vac Rated: Max. 346/600 Vac, Phase-Ground 300 Vac, Surge 4.0 kV
Linear Measuring Range: 1.25 × Vrated
Frequency Range: 50/60 Hz (30 to 85 Hz)
Input Impedance: 0.498 MΩ (120V), 2.0 MΩ (480V)
Current Inputs (Isolated): Rated 1A or 5A, Linear Range 1.5 × Irated, Burden <0.15 VA
Short-Time Current Rating: 50× Irated (1A), 10× Irated (5A) for 1 second
Discrete Inputs: 8 isolated inputs, 12/24 Vdc (8-40 Vdc), Input Resistance ~20 kΩ
Relay Outputs: 6 potential-free contacts, AgGdO material
Communication Interfaces: 1 CAN interface, 1 RS-485 interface
Dimensions (LS-521): 219 x 171 x 61 mm (W x H x D), Front Cutout: 186 x 138 mm
Dimensions (LS-511): 190 x 167 x 47 mm (W x H x D)
Event Log Capacity: 300 entries with real-time clock (battery backup)
LED Indicators: 8 configurable LEDs (LS-511 only)
Languages Supported: English, German, Spanish, French, Italian, Portuguese, Japanese, Chinese, Russian, Turkish, Polish
