VIBRO METER IQS900 204-900-000-011 A1-B21-C1-H10-I0 Signal conditioner

VIBRO METER IQS900 204-900-000-011 A1-B21-C1-H10-I0 Signal conditioner

Details of the module

Voltage at min. / max. gap : −1.6 V / −17.6 V
Measurement range : 16 V (corresponding to 12 mm)
Current at min. / max. gap : −15.5 mA / −20.5 mA
Measurement range : 5 mA (corresponding to 2 or 4 mm)
Output sensitivity : See Operation on page 3 and IQS900 signal conditioner on
page 18
Nominal output signal
• Without diagnostics : −15.5 to −20.5 mA
• With diagnostics : −15.5 to −20.5 mA indicates normal operation.
Other current values (>−15.5 or <−20.5 mA) indicate a problem
with the measurement chain (sensor, cabling or signal conditioner).
Output impedance : >60 kΩ.

The IQS900 signal conditioner contains a high-frequency modulator/demodulator that supplies a driving signal to a

IQS900 sensor. This generates an electromagnetic field in the tip of the sensor, which generates eddy-currents in the

metallic target. When the target moves, the eddy-currents change, which causes a change in the electrical characteristics

of the TQ9xx that the signal conditioner converts into a signal that is proportional to the distance to the target.
The IQS900’s output is an analogue signal consisting of a dynamic component (AC) that corresponds to the measured

vibration (displacement) and a quasi-static component (DC) that corresponds to the measured gap. The output can

be configured as a current or a voltage signal, suitable for transmission to a monitoring system via current (2-wire) or

voltage (3-wire) transmission cables, respectively.

Frequently asked questions：
1.What shipping methods are used for IQS900 204-900-000-011 A1-B21-C1-H10-I0?
Major carriers like FedEx, DHL, and UPS are primarily used for worldwide delivery.
2.Do you provide warranty as standard?
We provide a full 12-month warranty for the IQS900 204-900-000-011 A1-B21-C1-H10-I0. So, if you have any problems

within 12 months from the date of delivery, then you can contact our Team who will be happy to help and explain what

your next steps should be.
3.How do I get the price of  IQS900 204-900-000-011 A1-B21-C1-H10-I0?
Please contact our Sales Manager Ms. Lisa for a discount exclusive quote, Email sales7@amikon.cn/

WhatsApp : +86 18965423501.
