Mean Well NDR-480-48 Power Supply

Mean Well NDR-480-48 Power Supply

Mean Well NDR-480-48 Specification

Manufacturer: MEAN WELL
Product Number:NDR-480-48
Output Power: 480 W
Input Voltage: 90 VAC to 264 VAC, 127 VDC to 370 VDC
Number of Outputs:1 Output
Output Voltage-Channel 1:48 VDC
Output Current-Channel 1:10 A
Industry:Industrial
Length:128.5 mm (5.059 in)
Width:85.5 mm (3.366 in)
Height:125.2 mm (4.929 in)
Series:NDR-480

Mean Well NDR-480-48 Description

The NDR-480 is a cost-effective, slim 480W DIN rail power supply series designed for installation on TS-35/7.5 or

TS-35/15 mounting rails.  With a compact width of 85.5 mm, it allows for space-saving integration inside control

cabinets.  The series supports a full-range AC input from 90VAC to 264VAC and complies with BS EN/EN61000-3-2,

the EU standard regulating harmonic current.

Constructed with a metal housing, the NDR-480 enhances heat dissipation and achieves high efficiency—up to 92.5%.

It operates reliably within an ambient temperature range of -20°C to +70°C under natural air convection.  Featuring a

constant current mode for overload protection, it is suitable for a wide variety of inductive and capacitive loads.

With comprehensive protection features and certifications for industrial control equipment (including UL508,

TUV BS EN/EN62368-1, etc.), the NDR-480 offers a highly competitive power supply solution for industrial applications.
