MTL 9468-ET Ethernet Isolator
-Product Parameters-
Input Voltage: 24 V DC (range 20–30 V)
Input Current: 220 mA
Input Protection: Fuse and supply reversal diode
General Purpose Ethernet: 10/100 Base‑T
Ethernet Connector: RJ45
Intrinsically Safe (IS) Ethernet: 10/100 Base‑T
IS Ethernet Connector: RJ45
Operating Temperature: –40 °C to +70 °C
Storage Temperature: –40 °C to +70 °C
Relative Humidity: 5–95 % RH (non‑condensing)
The 9468-ET 10/100Mbps, lsolating Ethernet Barrier allows theinterconnection of a Zone 2 or uncertified safe area
device to theintrinsically safe 9400-ET range of Ethernet networking products,operating in the hazardous area. The
isolating barrier provides a compact altemnative solution to fibreoptic cable and media converters and for when it is
desirable to useCat5e cables in preference to fibre.
The 9468-ET is designed for Zone 2 hazardous-area mountinginside a suitable enclosure and has intrinsically safe
ATEX andlECEx approvals, together with iS approval for USA and Canada. FMDivision 2 mounting approval is pending.
The ATEX and IECExapprovals cover both surface industry and mining applications.
10/100Mb Ethernet twisted pair (Cat5e) RJ45 connections (100metreslength max.). These RJ45 ports provide total
galvanic isolation(Um=253Vac) from safe to hazardous areas.
