Introduction to the Bachmann DIO16-C Module

The Bachmann DIO16-C module is an integral part of the Bachmann M1 automation system, offering a comprehensive solution for digital input and output operations.   With its 16 channels that facilitate both input and output functionality, this module is designed to enhance the control and monitoring of various industrial devices and processes.



Specifications of the DIO16-C Module

To fully appreciate the capabilities of the DIO16-C module, it’s essential to consider its specifications:
Power Supply Voltage: Operates at 24V DC
Input Channels: 8 digital inputs
Output Channels: 8 digital outputs
Input Signal Type: Compatible with a range of digital signals, including sensors and switches
Output Signal Type: Can be configured for relay outputs or transistor outputs
Input Current: 5 mA (typical per channel)
Response Time: Less than 1 ms for digital signals
Isolation Voltage: 500 V (between input/output and bus)
Operating Temperature Range: -20°C to 60°C
Storage Temperature Range: -40°C to 85°C
Humidity: Operates effectively in 5% to 95% humidity (non-condensing)
Weight: Approximately 300 g

Key Features of the Bachmann DIO16-C Module

The DIO16-C module is equipped with several features that enhance its functionality and ease of use:
Modular Design: This module easily integrates into the Bachmann M1 control system, allowing for flexible configuration and expansion based on project requirements.
Dual Functionality: By supporting both digital input and output in a single module, it minimizes the need for multiple modules, saving space and reducing costs.
Compact Size: Its space-saving design makes it suitable for installation in tight environments, maximizing the use of available space.
LED Indicators: Each channel is equipped with status LEDs, providing straightforward monitoring of input and output states for quick diagnostics.
Robust Construction: Built to withstand harsh industrial environments, the module ensures reliable operation even under challenging conditions.
Configurable Options: Users can configure the module for various applications using Bachmann’s software tools, enhancing its adaptability.
High Reliability: Designed for dependable performance, the DIO16-C module is ideal for demanding automation applications.

Frequently Asked Questions (FAQ)

What is the operating voltage of the module?
The Bachmann DIO16-C module operates at 24V DC.

How many input channels does the module support?
The module supports 16 input channels.

What types of input signals are supported?
It is compatible with both dry contact and live contact switch signals.

What is the response time of the module?
The typical response time is 0.5 ms.

What is the operating temperature range of the module?
The operating temperature range is from 0°C to 60°C.

How is the wiring done?
Wiring is simplified by the inclusion of terminal blocks, allowing for easy connections.
