ABB DPMP-02 3AXD50000009374 Mounting kit

ABB DPMP-02 3AXD50000009374 Mounting kit

ABB DPMP-02 3AXD50000009374 Specification

Mounting Type: Surface mount on cabinet doors
Compatible Control Panels: ACH-CP-H, ACS-AP-H, ACS-AP-I, ACS-AP-S, ACS-AP-W, ACS-BP-S
Cabinet Door Thickness: 1.5 mm to 30 mm (0.059 in to 1.18 in)
Cutout Diameter: 22.3 mm (0.88 in)
Degree of Protection:
IP65 / UL Type 12 when the panel is mounted
IP20 when the panel is not mounted
Cable Type: 3-meter CAT5E UTP with RJ45 connectors
Operating Temperature Range: -40°C to +70°C (-40°F to +158°F)

ABB DPMP-02 3AXD50000009374 Description

The ABB DPMP-02 (3AXD50000009374) is a high-quality panel surface mounting kit designed to enable the remote

installation of ABB control panels onto cabinet doors or flat surfaces.  It provides a reliable and secure solution for

positioning control panels in more accessible or ergonomic locations within industrial environments.
This kit includes a mounting platform, locking nut, and a 3-meter CAT5E UTP cable with RJ45 connectors, making it

easy to connect the panel to the drive system.  It is compatible with a variety of ABB control panels, such as ACS-AP,

ACS-AP-X, and ACS-BP-S.  When used with ACS480 or ACS580 drives, a panel bus adapter is required.
Offering IP65 / UL Type 12 protection when properly installed, the DPMP-02 kit ensures resistance to dust, moisture,

and other environmental factors.  It is ideal for use in demanding industrial settings where durability, ease of access,

and protection are essential for operational efficiency.
