1756-PB75 Standard Power Supply

1756-PB75 Standard Power Supply

-Product Parameters-

Weight: 2.19 lbs (0.99 kg)
Location: 1756 Chassis Left Side
Module Type: Standard Power Supply
Nominal Input Voltage: 24 VDC
Input Voltage Range: 18–32 VDC
Input Power: 95 W
Power Output: 75 W at 60 °C
Chassis Compatibility: Series B;  Series C
Operating Temperature: 32–140 °F (0–60 °C)
Maximum Inrush Current: 30 A

The 1756-PB75 is a Standard power supply.  This power supply is a DC powered module, mainly used to deliver

backplane power and enable module operation.  This power supply is mounted on the left most side of a particular

chassis.
The 1756-PB75 is compatible with most of chassis, particularly Series B and Series C 1756-A4, 1756-A7, 1756-A10,

1756-A13, 1756-A17 chassis.  When terminating incoming power connection to this power supply, recommended wire

size is 2.5 mm2 or 14 American Wire Gauge (AWG) solid or stranded copper wire with insulation rating of 90 °C (194 °F),

or higher and maximum insulation thickness of 1.2 mm (3/64 in.).  Tighten screw with Torque of 0.565 N-m (5 lb-in).

This power supply has physical dimension of 14.0 (H) x 11.2 (W) x 14.5 cm (D) (5.51 x 4.41 x 5.71 in and weighs

0.95 kg (2.10 lb).
